LF90

LF90 is a control lever designed for single or double operation of propulsion machinery, bow or stern thruster etc.

LF90 is a control lever designed for single or double operation of propulsion machinery, bow or stern thruster etc. The unit is designed for electronic control and is equipped with potentiometers. The LF90 is small, robust and reliable.

Technical description

  • The side covers are in black coated aluminium
  • Shaft is in flat finished stainless steel
  • Handle is in flat finished POM (plastic material)
  • Scale: Self adhesive on acrylic bow
  • Scale light: 24 volts
  • Standard potentiometer: 5 kΩ
  • Potentiometer operation: Tooth belt

Options

  • Spring loaded return to neutral position
  • Built-in switches
  • Termination
  • Panel plate 96×96 mm, enclosure according to IP66
  • Colour
  • Motorised axes
  • A range of different scale foils
  • Custom design (scale, panel plate, potentiometer, shafts and handles)

The control lever tested (worst case) and certified by Det Norske Veritas.

Specification details

Side covers

Black coated aluminium

Shaft

Dull surface, stainless steel

Handle Dull surface, POM

Scale

Self adhesive on acrylic bow

Standard scale light 24 volts

Standard potmeter 5K

Potmeter operation Tooth belt

Standard termination 16 pins contact with plug

Enclosure

IP66 (panel plate)

Type approval

EN/IEC 60945, ABS, BV, DNV, GLKR, LR, NK, RINA, PRS, RS, CRS

Options, single and double

Spring-loaded return to neutral position
Built-in switches
Detents, limited deflection
Various handles and shafts
Handle interlock on/off on straight shafts
Panel plate 96x96 mm, IP66 enclosure
Motorized (see separate product sheet)
A range of scale foils, thruster or propulsion
Integrated scale light

Other options on request
